1. Core Function: Oil Control and Sealing
The primary mission of the oil scraper ring is the precise control of lubricating oil. Its specific functions are:
- Scraping Excess Oil: As the piston moves downward, the ring’s sharp edges scrape off excess oil from the cylinder wall.
- Uniform Oil Distribution: It leaves a thin, uniform film of oil on the cylinder wall for proper lubrication.
- Auxiliary Sealing: It assists in preventing gases from leaking into the crankcase.
The ultimate goal is to prevent oil from entering the combustion chamber (“oil burning”), ensuring engine power, reducing emissions, and controlling oil consumption.
2. Key Materials and Characteristics
Common materials include:
- Alloy Cast Iron: The most common material, often nodular graphite iron with chromium or molybdenum for wear resistance, toughness, and heat fatigue resistance.
- Stainless Steel: Used in high-performance engines for its strength, elasticity, and corrosion resistance.
- Coatings: Surfaces are often chrome-plated or molybdenum-coated to reduce friction and increase wear resistance.
3. Main Structural Types
- Slot-and-Drill Type: A common one-piece design with slots for oil return. Simple and cost-effective.
- Steel Strip Composite Type: The modern standard for high-performance engines. Consists of two thin steel rails and an expander spacer. Excellent conformability and oil control.
- Nose Type: Features a protrusion for scraping; less common today.
4. Core Advantages Summary
Modern scraper rings offer:
- Efficient Oil Control: Prevents excessive oil consumption.
- High Conformability: Adapts well to cylinder wall distortions.
- Reduced Friction: Lightweight design aids fuel economy.
- Durability: High-performance materials ensure longevity.
In conclusion, the oil scraper ring is a vital component, crucial for developing more efficient, cleaner, and durable engines.
